Assignment 5A: Patient Queue

cd DIRECTORY_WHERE_DEMO_JAR_IS_STOREDjava -jar JAR_FILE_NAME

cd /users/jsmith12/Documents/106bjava -jar hw2.jar

cd C:\users\jsmith12\Documents\106bjava -jar hw2.jar

Problem Description:

In this problem you will write a class called a patient queue ("PQ" for short) that manages a waiting line of patients to be processed at a hospital.

In this class we have learned about queues that process elements in a first-in, first-out (FIFO) order. But FIFO is not the best order to assist patients in a hospital, because some patients have more urgent and critical injuries than others. As each new patient checks in at the hospital, the staff assesses their injuries and gives that patient an integer priority rating, with smaller integers representing greater urgency. (For example, a patient of priority 1 is more urgent and should receive care before a patient of priority 2.)

Once a doctor is ready to see a patient, the patient with the most urgent (smallest) priority is seen first. That is, regardless of the order in which you add/enqueue the elements, when you remove/dequeue them, the one with the most urgent priority (smallest integer value) comes out first, then the second-smallest, and so on, with the least urgent priority (largest integer value) item coming out last. A queue that processes its elements in order of increasing priority like this is also called a priority queue.

1) LinkedPQ:

This section describes the first of two implementations that you will write, named LinkedPQ. We strongly recommend that you write this implementation in its entirety before attempting the more difficult second implementation described later in this document.

Your implementation of the patient queue will be a LinkedPQ class that uses a singly linked list as its internal data storage. The elements of the linked list are stored in sorted order internally. As new elements are enqueued, you should add them at the appropriate place in the linked list so as to maintain the sorted order. The primary benefit of this implementation is that when removing a patient to process them, you do not need to search the linked list to find the smallest element and remove/return it; it is always at the front of the list. Enqueuing is slower, because you must search for the proper place to enqueue new elements, but dequeue/peeking and general overall performance are fairly good.

If two patients in the queue have the same priority, you will break ties by choosing the patient who arrived earliest with that priority. This means that if a patient arrives at priority K and there are already other patients in the queue with priority K, your new patient should be placed after them.

For example, if the following patients arrive at the hospital in this order:

• "Dolores" with priority 5
• "Bernard" with priority 4
• "Arnold" with priority 8
• "William" with priority 5
• "Teddy" with priority 5
• "Ford" with priority 2

Then if you were to dequeue the patients to process them, they would come out in this order: Ford, Bernard, Dolores, William, Teddy, Arnold. The following is a diagram of the internal linked list state that a LinkedPQ should have after enqueuing the elements listed previously:

front -> {2:Ford} -> {4:Bernard} -> {5:Dolores} -> {5:William} -> {5:Teddy} -> {8:Arnold}

Notice that some of the elements have the same priority, such as 5:Dolores, 5:William, and 5:Teddy. The relative order of these tied elements is based on the order they were added, with Dolores appearing first because she was added earliest to the queue, and so on.

Implementation Details:

(It is worth noting that outside of the context of this homework assignment, internally a given implementation of a priority queue might not actually store its elements in sorted order; all that matters is that when they are dequeued, they come out in sorted order by priority. This difference between the external expected behavior of the priority queue and its true internal state can lead to interesting differences in implementation.)

As stated previously, your LinkedPQ class must use a sorted linked list as its internal data storage. This class is required to have only a single private member variable inside it: a pointer to the front node of your list. This pointer must be set to a null value (NULL) if the list is empty.

We supply you with a PNode structure (in pnode.h/cpp) that is a small structure representing a single node of the linked list. Each PNode stores information about one patient in the queue, including a string for the patient's name and an integer for their priority, along with a pointer to a next node. You should use this structure to store the elements of your queue along with their priorities. Its declaration looks like the following:

struct PNode {
    string name;
    int priority;
    PNode* next;

    // constructor - each parameter is optional
    PNode(string name = "", int priority = 0, PNode* next = NULL);
};

As stated previously, the elements of the linked list are stored in sorted order internally. As new elements are enqueued, you should add them at the appropriate place in the linked list so as to maintain the sorted order. The primary benefit of this implementation is that when dequeuing, you do not need to search the linked list to find the element with most urgent priority to remove/return it; it is always at the front of the list. Enqueuing new patients is slower, because you must search for the proper place to enqueue them, but dequeuing a patient to process them is very fast, because they are at the front of the list.

As shown previously, the following is a diagram of the internal linked list state of a LinkedPQ after enqueuing the elements listed previously:

front -> {2:Ford} -> {4:Bernard} -> {5:Dolores} -> {5:William} -> {5:Teddy} -> {8:Arnold}

front -> {2:Ford} -> {4:Bernard} -> {5:Dolores} -> {5:William} -> {5:Teddy} -> {8:Arnold}
                                                                   ^
                                                                   |
                                                        current ---+

front -> {2:Ford} -> {4:Bernard} -> {5:Dolores} -> {5:William} -> {5:Teddy}       {8:Arnold}
                                                                   ^      |        ^
                                                                   |      v        |
                                                        current ---+      {5:Stubbs}

front -> {2:Ford} -> {4:Bernard} -> {5:Dolores} -> {5:William} -> {5:Teddy}       {8:Arnold}
                                                                          |        ^
                                                                          v        |
                                                                          {5:Stubbs}

Suppose you next wanted to insert the value "Maeve" with priority 1 into the list shown above. You would insert the new node at the front of the list, as shown below:

front     {2:Ford} -> {4:Bernard} -> {5:Dolores} -> {5:William} -> {5:Teddy} -> {5:Stubbs} -> {8:Arnold}
    |      ^
    v      |
    {1:Maeve}

LinkedPQ Operations:

Your class must support all of the following operations. Each member must run within the Big-Oh runtime noted; the N in this context means the length of the linked list.

The headers of every member must match those specified above. Do not change the parameters or function names.

Constructor/destructor: Your class must define a parameterless constructor. Since your implementation allocates dynamic memory (using new), you must ensure that there are no memory leaks by freeing any such allocated memory at the appropriate time. This will mean that you will need a destructor to free the memory for all of your nodes.

Helper functions: The members listed previously represent your class's required behavior. But you may add other member functions to help you implement all of the appropriate behavior. Any other member functions you provide must be private. Remember that each member function of your class should have a clear, coherent purpose. You should provide private helper members for common repeated operations. Make a member function and/or parameter const if it does not perform modification of the object's state.

You will also need to do the following:

Add descriptive comments to linkedpq.h/cpp. Both files should have top-of-file headers; one file should have header comments atop each member function, either the .h or .cpp; and the .cpp should have internal comments describing the details of each function's implementation.

Declare your necessary private member variable in linkedpq.h, along with any private member functions you want to help you implement the required public behavior. Your inner data storage must be a singly linked list of patient nodes; do not use any other collections or data structures in any part of your code.

Implement the bodies of all member functions and constructors in linkedpq.cpp.

Make member functions const as appropriate. Some of the member functions you will write do not modify the state of the patient queue. For all such functions, mark them as const at the end of their headers in the .h and .cpp files in your code. For example, if a member named foo doesn't modify the list, you should change its header to:

class LinkedPQ {
    ...
    void functionName() const;
};

Other than adding const to some headers, you should not modify the provided public member headers in any way.

Here are a few other constraints we expect you to follow in your implementation:

You should not make unnecessary passes over the linked list. For example, when enqueuing an element, a poor implementation would be to traverse the entire list once to count its size and to find the proper index at which to insert, and then make a second traversal to get back to that spot and add the new element. Do not make such multiple passes. Also, keep in mind that your queue class is not allowed to store an integer size member variable; you must use the presence of a null next pointer to figure out where the end of the list is and how long it is.

Duplicate patient names and priorities are allowed in your queue. For example, the upgradePatient operation should affect only a single occurrence of a patient's name (the first one found). If there are other occurrences of that same value in the queue, a single call to upgradePatient shouldn't affect them all.

You are not allowed to use a sort function or library to arrange the elements of your list, nor are you allowed to create any temporary or auxiliary data structures anywhere in your code. You must implement all behavior using only the one linked list of nodes as specified.

You will need pointers for several of your implementations, but you should not use pointers-to-pointers (for example, PNode**). If you like, you are allowed to use a reference to a pointer (e.g. PNode*&).

You should not create any more PNode objects than necessary. For example, if a LinkedPQ contains 6 elements, there should be exactly 6 PNode objects in its internal linked list; no more, no less. You shouldn't, say, have a seventh empty "dummy" node at the front or back of the list that serves only as a marker, nor should you create a new PNode that is just thrown away or discarded without being used as part of the linked list. You can declare as many local variable pointers to PNodes as you like.

Development Strategy and Hints:

Draw pictures: When manipulating linked lists, it is often helpful to draw pictures of the linked list before, during, and after each of the operations you perform on it. Manipulating linked lists can be tricky, but if you have a picture in front of you as you're coding it can make your job substantially easier.

List states: When processing a linked list, you should consider different list states and transitions between them in your code as you add and remove elements. You should also think about the effect of adding a node in the front, middle, and back of the list of a given state.

front /

          +---+---+
front --> | ? | / |
          +---+---+

          +---+---+     +---+---+        +---+---+    +---+---+
front --> | ? |   | --> | ? |   |--> ... | ? |   |--> | ? | / |
          +---+---+     +---+---+        +---+---+    +---+---+

Heap Implementation (optional extension)

As discussed in lecture, a binary heap is an unfilled array that maintains a "heap ordering" property where each index i is thought of as having two "child" indexes, i * 2 and i * 2 + 1, and where the elements must be arranged such that "parent" indexes always store more urgent priorities than their "child" indexes. To simplify the index math, we will leave index 0 blank and start the data at an overall parent "root" or "start" index of 1. One very desirable property of a binary heap is that the most urgent-priority element (the one that should be returned from a call to peek or dequeue) is always at the start of the data in index 1. For example, the six elements listed in the previous pages could be put into a binary heap as follows. Notice that the most urgent element, "t":2, is stored at the root index of 1.

index     0       1       2       3       4       5       6       7       8       9
      +-------+-------+-------+-------+-------+-------+-------+-------+-------+-------+
value |       | "t":2 | "m":5 | "b":4 | "x":5 | "q":5 | "a":8 |       |       |       |
      +-------+-------+-------+-------+-------+-------+-------+-------+-------+-------+
size = 6
capacity = 10

As discussed in lecture, adding (enqueuing) a new element into a heap involves placing it into the first empty index (7, in this case) and then "bubbling up" or "percolating up" by swapping it with its parent index (i/2) so long as it has a more urgent (lower) priority than its parent. We use integer division, so the parent of index 7 = 7/2 = 3. For example, if we added "y" with priority 3, it would first be placed into index 7, then swapped with "b":4 from index 3 because its priority of 3 is less than b's priority of 4. It would not swap any further because its new parent, "t":2 in index 1, has a lower priority than y. So the final heap array contents after adding "y":3 would be:

index     0       1       2       3       4       5       6       7       8       9
      +-------+-------+-------+-------+-------+-------+-------+-------+-------+-------+
value |       | "t":2 | "m":5 | "y":3 | "x":5 | "q":5 | "a":8 | "b":4 |       |       |
      +-------+-------+-------+-------+-------+-------+-------+-------+-------+-------+
size = 7
capacity = 10

Removing (dequeuing) the most urgent element from a heap involves moving the element from the last occupied index (7, in this case) all the way up to the "root" or "start" index of 1, replacing the root that was there before; and then "bubbling down" or "percolating down" by swapping it with its more urgent-priority child index (i*2 or i*2+1) so long as it has a less urgent (higher) priority than its child. For example, if we removed "t":2, we would first swap up the element "b":4 from index 7 to index 1, then bubble it down by swapping it with its more urgent child, "y":3 because the child's priority of 3 is less than b's priority of 4. It would not swap any further because its new only child, "a":8 in index 6, has a higher priority than b. So the final heap array contents after removing "t":2 would be:

index     0       1       2       3       4       5       6       7       8       9
      +-------+-------+-------+-------+-------+-------+-------+-------+-------+-------+
value |       | "y":3 | "m":5 | "b":4 | "x":5 | "q":5 | "a":8 |       |       |       |
      +-------+-------+-------+-------+-------+-------+-------+-------+-------+-------+
size = 6
capacity = 10

A key benefit of using a binary heap to represent a priority queue is efficiency. The common operations of enqueue and dequeue take only O(log N) time to perform, since the "bubbling" jumps by powers of 2 every time. The peek operation takes only O(1) time since the most urgent-priority element's location is always at index 1.

If two patients in the queue have the same priority, you will break ties by choosing the patient who arrived earliest with that priority. This means that if a patient arrives at priority K and there are already other patients in the queue with priority K, your new patient should be placed after them.

Changing the priority of an existing value involves looping over the heap to find that value, then once you find it, setting its new priority and "bubbling up" that value from its present location, somewhat like an enqueue operation.

For the heap PQ, when the array becomes full and has no more available indexes to store data, you must resize it to a larger array. Your larger array should be a multiple of the old array size, such as double the size. You must not leak memory; free all dynamically allocated arrays created by your class.

Hint: In order to test your binary heap, add the line #include heappq.h to hospitalmain.cpp, and the console will give you an option of which PQ to test.

Style Details:

As in other assignments, you should follow our Style Guide for information about expected coding style. You are also expected to follow all of the general style constraints emphasized in the Homework 1-4 specs, such as the ones about good problem decomposition, parameters, redundancy, using proper C++ idioms, and commenting. The following are additional points of emphasis and style constraints specific to this problem. (Some of these may seem overly strict or arbitrary, but we need to constrain the assignment to force you to properly practice pointers and linked lists as intended.)

Commenting: Add descriptive comments to your .h and .cpp files. Both files should have top-of-file headers. One file should have header comments atop each member function (either the .h or .cpp; your choice). The .cpp file should have internal comments describing the details of each function's implementation.

Restrictions on pointers: The whole point of this assignment is to practice pointers and linked lists. Therefore, do not declare or use any other collections in any part of your code; all data should be stored in your linked list of nodes. There are some C++ "smart pointer" libraries that manage pointers and memory automatically, allocating and freeing memory as needed; you should not use any such libraries on this assignment.

Restrictions on private member variables: As stated previously, the only member variable (a.k.a. instance variable; private variable; field) you are allowed to have in your LinkedPQ is a PNode* pointer to the front of your list. You may not have any other member variables. Do not declare an int for the list size. Do not declare members that are pointers to any other nodes in the list. Do not declare any collections or data structures as members. Similarly, the only member variable you are allowed to have in your SkipListPQ is a pointer to the front header SkipNode.

Restrictions on modifying member function headers: Please do not make modifications to the PQ class's public constructor or public member functions' names, parameter types, or return types. Our client code should be able to call public member functions on your queue successfully without any modification.

Restrictions on creation and usage of nodes: In your LinkedPQ, the only place in your code where you should be using the new keyword is in the newPatient function. No other members should use new or create new nodes under any circumstances. You also should not be modifying or swapping nodes' name values after they are added to the queue. In other words, you should implement all of the linked list / patient queue operations like upgradePatient by manipulating node pointers, not by creating entirely new nodes and not by modifying "data" of existing nodes. In your SkipListPQ the same overall constraint applies, though you are also allowed to create a new node in your constructor to use as your dummy header.

You also should not create any more PNode structures than necessary. For example, if the client has called newPatient 6 times on a LinkedPQ, your code should have created exactly 6 total PNode objects; no more, no less. You shouldn't, say, have a seventh empty "dummy" node at the front or back of the LinkedPQ's list that serves only as a marker, and you shouldn't accidentally create a temporary node object that is lost or thrown away. You can declare as many local variable pointers to nodes as you like. The SkipListPQ is allowed to have a dummy header at the front of the list as described previously.

Restrictions on traversal of the list: Any function that modifies your linked list should do so by traversing across your linked list a single time, not multiple times. For example, in functions like newPatient, do not make one traversal to find a node or place of interest and then a second traversal to manipulate/modify the list at that place. Do the entire job in a single pass. The one exception to this rule is upgradePatient, which is allowed to make two passes, one to find/remove the element and a second to add it with its new priority.

Do not traverse the list farther than you need to. That is to say, once you have found the node of interest, do not unnecessarily walk across the rest of the list; break/return out of code as needed once the work is done. In the SkipListPQ you should walk along the highest levels of the PQ whenever possible and appropriate, such as when adding new nodes or searching for existing nodes.

Avoiding memory leaks: This item is listed under Style even though it is technically a functional requirement, because memory leakage is not usually visible while a program is running. To ensure that your class does not leak memory, you must delete all of the node objects in your linked list whenever data is removed or cleared from the list. You must also properly implement a destructor that deletes the memory used by all of the linked list nodes inside your LinkedPQ object. It is difficult to be certain that code does not contain memory leaks; if you want to try to verify this, you could consider putting a print statement or counter in the list node class that prints every time a node is created or destroyed. Counting the number of these messages would tell you whether every allocated node was freed by your program.

Frequently Asked Questions (FAQ):

For each assignment problem, we receive various frequent student questions. The answers to some of those questions can be found by clicking the link below.

Possible Extra Features:

For this problem, most good extra feature ideas involve adding operations to your queue beyond those specified. Here are some ideas for extra features that you could add to your program:

• Known list of diseases: Instead of, or in addition to, asking for each new patient's priority, ask what illness or disease they have, and use that to initialize the priority of newly checked-in patients. Then keep a table of known diseases and their respective priorities. For example, if the patient says that they have the flu, maybe the priority is 5, but if they say they have a broken arm, the priority is 2.
• Other kinds of PQs: Write additional classes that implement the PQ operations in different ways. For example, learn about various kinds of heaps that can be used to implement a priority queue. If you write files extrapq.h and extrapq.cpp, our main file can be modified without too much work to make it use your queues alongside the required ones.
• Merge two queues: Write a member function that accepts another patient queue of the same type and adds all of its elements into the current patient queue. Do this merging "in place" as much as possible; for example, if you are merging two linked lists, directly connect the node pointers of one to the other as appropriate.
• Deep Copy: Make your queue properly support the = assignment statement, copy constructor, and deep copying. Google about the C++ "Rule of Three" and follow that guideline in your implementation.
• Iterator: Write a class that implements the STL iterator type and begin and end member functions in your queue, which would enable "for-each" over your PQ. This requires knowledge of the C++ STL library.
• Other: If you have your own creative idea for an extra feature, ask your SL and/or the instructor about it.

Indicating that you have done extra features: If you complete any extra features, then in the comment heading on the top of your program, please list all extra features that you worked on and where in the code they can be found (what functions, lines, etc. so that the grader can look at their code easily).

Submitting a program with extra features: Since we use automated testing for part of our grading process, it is important that you submit a program that conforms to the preceding spec, even if you want to do extra features. If your feature(s) cause your program to change the output that it produces in such a way that it no longer matches the expected sample output test cases provided, you should submit two versions of your program file: a first one with the standard file name without any extra features added (or with all necessary features disabled or commented out), and a second one whose file name has the suffix -extra.cpp with the extra features enabled. Please distinguish them in by explaining which is which in the comment header. Our turnin system saves every submission you make, so if you make multiple submissions we will be able to view all of them; your previously submitted files will not be lost or overwritten.
